SiC Diode 碳化硅二极管

  • 首页
  • SiC Diode 碳化硅二极管

SiC Diode 碳化硅二极管

SiC Diode 碳化硅二极管是一种高效、高耐压的功率半导体器件，具备极低的开关损耗和优异的高温性能。它广泛应用于电动汽车、可再生能源和高频电源设备中，大幅提升系统效率和可靠性

check
Product
Data Sheet
Product Status
Qualification
Package Type
Configuration
Technology
V RRM
I FMax
I FSMMax
V Ftyp.
V FMax
IR Max
Q Ctyp.
Mounting
HCA170S25D1 Active Industrial TO247 2L Single eSiC D1 1700 V 25.0 A 191.0 A 1.5 V 1.8 V 100 uA 173 nC Through Hole
HCW120D40D1 Active Industrial TO247 3L Common Cathode eSiC D1 1200 V 40.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC (Per Leg) Through Hole
HCW120D40D1A Active Automotive TO247 3L Common Cathode eSiC D1 1200 V 40.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC (Per Leg) Through Hole
HCA120S40D1 Active Industrial TO247 2L Single eSiC D1 1200 V 40.0 A 225.0 A 1.39 V 1.7 V 100 uA 241 nC Through Hole
HCO120S40D1 Active Industrial Die Single eSiC D1 1200 V 40.0 A 225.0 A 1.39 V 1.7 V 100 uA 241 nC Surface Mount
HCW120D30D1 Active Industrial TO247 3L Common Cathode eSiC D1 1200 V 30.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC (Per Leg) Through Hole
HCW120D30D1A Active Automotive TO247 3L Common Cathode eSiC D1 1200 V 30.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC (Per Leg) Through Hole
HCA120S30D1 Active Industrial TO247 2L Single eSiC D1 1200 V 30.0 A 180.0 A 1.39 V 1.7 V 100 uA 180 nC Through Hole
HCO120S30D1 Active Industrial Die Single eSiC D1 1200 V 30.0 A 180.0 A 1.39 V 1.7 V 100 uA 180 nC Surface Mount
HCW120D20D1 Active Industrial TO247 3L Common Cathode eSiC D1 1200 V 20.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC (Per Leg) Through Hole
HCW120D20D1A Active Automotive TO247 3L Common Cathode eSiC D1 1200 V 20.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC (Per Leg) Through Hole
HCA120S20D1 Active Industrial TO247 2L Single eSiC D1 1200 V 20.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC Through Hole
HCA120S20D1A Active Automotive TO247 2L Single eSiC D1 1200 V 20.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC Through Hole
HCH120S20D1 Active Industrial TO220 2L Single eSiC D1 1200 V 20.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC Through Hole
HCB120S20D1 Active Industrial D2PAK Single eSiC D1 1200 V 20.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC Surface Mount
HCO120S20D1 Active Industrial Die Single eSiC D1 1200 V 20.0 A 135.0 A 1.39 V 1.7 V 100 uA 121 nC Surface Mount
HCW120D15D1 Active Industrial TO247 3L Common Cathode eSiC D1 1200 V 15.0 A 61.0 A 1.39 V 1.7 V 100 uA 53 nC (Per Leg) Through Hole
HCW120D15D1A Active Automotive TO247 3L Common Cathode eSiC D1 1200 V 15.0 A 61.0 A 1.39 V 1.7 V 100 uA 53 nC (Per Leg) Through Hole
HCA120S15D1 Active Industrial TO247 2L Single eSiC D1 1200 V 15.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC Through Hole
HCA120S15D1A Active Automotive TO247 2L Single eSiC D1 1200 V 15.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC Through Hole
HCH120S15D1 Active Industrial TO220 2L Single eSiC D1 1200 V 15.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC Through Hole
HCO120S15D1 Active Industrial Die Single eSiC D1 1200 V 15.0 A 106.0 A 1.39 V 1.7 V 100 uA 92 nC Surface Mount
HCW120D10D1 Active Industrial TO247 3L Common Cathode eSiC D1 1200 V 10.0 A 40.0 A 1.39 V 1.7 V 100 uA 32 nC (Per Leg) Through Hole
HCW120D10D1A Active Automotive TO247 3L Common Cathode eSiC D1 1200 V 10.0 A 40.0 A 1.39 V 1.7 V 100 uA 32 nC (Per Leg) Through Hole
HCA120S10D1 Active Industrial TO247 2L Single eSiC D1 1200 V 10.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC Through Hole
HCA120S10D1A Active Automotive TO247 2L Single eSiC D1 1200 V 10.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC Through Hole
HCH120S10D1 Active Industrial TO220 2L Single eSiC D1 1200 V 10.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC Through Hole
HCB120S10D1 Active Industrial D2PAK Single eSiC D1 1200 V 10.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC Surface Mount
HCO120S10D1 Active Industrial Die Single eSiC D1 1200 V 10.0 A 79.0 A 1.39 V 1.7 V 100 uA 63 nC Surface Mount
HCH120S08D1 Active Industrial TO220 2L Single eSiC D1 1200 V 8.0 A 61.0 A 1.39 V 1.7 V 100 uA 53 nC Through Hole
HCO120S08D1 Active Industrial Die Single eSiC D1 1200 V 8.0 A 61.0 A 1.39 V 1.7 V 100 uA 53 nC Surface Mount
HCH120S05D1 Active Industrial TO220 2L Single eSiC D1 1200 V 5.0 A 40.0 A 1.39 V 1.7 V 100 uA 32 nC Through Hole
HCO120S05D1 Active Industrial Die Single eSiC D1 1200 V 5.0 A 40.0 A 1.39 V 1.7 V 100 uA 32 nC Surface Mount
HCW120D60D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 1200 V 60.0 A 135.0 A 1.63 V 1.95 V 100 uA 121 nC (Per Leg) Through Hole
HCA120S60D1Q Active Industrial TO247 2L Single eSiC D1Q 1200 V 60.0 A 225.0 A 1.63 V 1.95 V 100 uA 241 nC Through Hole
HCW120D40D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 1200 V 40.0 A 106.0 A 1.54 V 1.85 V 100 uA 92 nC (Per Leg) Through Hole
HCW120D40D1QA Active Automotive TO247 3L Common Cathode eSiC D1Q 1200 V 40.0 A 106.0 A 1.54 V 1.85 V 100 uA 92 nC (Per Leg) Through Hole
HCA120S30D1Q Active Industrial TO247 2L Single eSiC D1Q 1200 V 30.0 A 145.0 A 1.59 V 1.9 V 100 uA 121 nC Through Hole
HCW65D40D1 Active Industrial TO247 3L Common Cathode eSiC D1 650 V 40.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC (Per Leg) Through Hole
HCW65D40D1A Active Automotive TO247 3L Common Cathode eSiC D1 650 V 40.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC (Per Leg) Through Hole
HCW65D30D1 Active Industrial TO247 3L Common Cathode eSiC D1 650 V 30.0 A 86.0 A 1.3 V 1.6 V 100 uA 61 nC (Per Leg) Through Hole
HCW65D30D1A Active Automotive TO247 3L Common Cathode eSiC D1 650 V 30.0 A 86.0 A 1.3 V 1.6 V 100 uA 61 nC (Per Leg) Through Hole
HCW65D20D1 Active Industrial TO247 3L Common Cathode eSiC D1 650 V 20.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC (Per Leg) Through Hole
HCW65D20D1A Active Automotive TO247 3L Common Cathode eSiC D1 650 V 20.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC (Per Leg) Through Hole
HCA65S20D1 Active Industrial TO247 2L Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Through Hole
HCA65S20D1A Active Automotive TO247 2L Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Through Hole
HCH65S20D1 Active Industrial TO220 2L Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Through Hole
HCF65S20D1 Active Industrial TO220F 2L Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Through Hole
HCB65S20D1 Active Industrial D2PAK Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Surface Mount
HCO65S20D1 Active Industrial Die Single eSiC D1 650 V 20.0 A 97.0 A 1.3 V 1.6 V 100 uA 77 nC Surface Mount
HCW65D16D1 Active Industrial TO247 3L Common Cathode eSiC D1 650 V 16.0 A 45.0 A 1.3 V 1.6 V 100 uA 31 nC (Per Leg) Through Hole
HCW65D16D1A Active Automotive TO247 3L Common Cathode eSiC D1 650 V 16.0 A 45.0 A 1.3 V 1.6 V 100 uA 31 nC (Per Leg) Through Hole
HCH65S16D1 Active Industrial TO220 2L Single eSiC D1 650 V 16.0 A 86.0 A 1.3 V 1.6 V 100 uA 61 nC Through Hole
HCO65S16D1 Active Industrial Die Single eSiC D1 650 V 16.0 A 86.0 A 1.3 V 1.6 V 100 uA 61 nC Surface Mount
HCH65S12D1 Active Industrial TO220 2L Single eSiC D1 650 V 12.0 A 64.0 A 1.3 V 1.6 V 100 uA 46 nC Through Hole
HCF65S12D1 Active Industrial TO220F 2L Single eSiC D1 650 V 12.0 A 64.0 A 1.3 V 1.6 V 100 uA 46 nC Through Hole
HCO65S12D1 Active Industrial Die Single eSiC D1 650 V 12.0 A 64.0 A 1.3 V 1.6 V 100 uA 46 nC Surface Mount
HCH65S10D1 Active Industrial TO220 2L Single eSiC D1 650 V 10.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC Through Hole
HCF65S10D1 Active Industrial TO220F 2L Single eSiC D1 650 V 10.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC Through Hole
HCB65S10D1 Active Industrial D2PAK Single eSiC D1 650 V 10.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC Surface Mount
HCD65S10D1 Active Industrial DPAK Single eSiC D1 650 V 10.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC Surface Mount
HCO65S10D1 Active Industrial Die Single eSiC D1 650 V 10.0 A 55.0 A 1.3 V 1.6 V 100 uA 39 nC Surface Mount
HCH65S08D1 Active Industrial TO220 2L Single eSiC D1 650 V 8.0 A 45.0 A 1.3 V 1.6 V 100 uA 32 nC Through Hole
HCF65S08D1 Active Industrial TO220F 2L Single eSiC D1 650 V 8.0 A 45.0 A 1.3 V 1.6 V 100 uA 32 nC Through Hole
HCB65S08D1 Active Industrial D2PAK Single eSiC D1 650 V 8.0 A 45.0 A 1.3 V 1.6 V 100 uA 32 nC Surface Mount
HCO65S08D1 Active Industrial Die Single eSiC D1 650 V 8.0 A 45.0 A 1.3 V 1.6 V 100 uA 32 nC Surface Mount
HCH65S06D1 Active Industrial TO220 2L Single eSiC D1 650 V 6.0 A 33.8 A 1.3 V 1.6 V 100 uA 24 nC Through Hole
HCF65S06D1 Active Industrial TO220F 2L Single eSiC D1 650 V 6.0 A 33.8 A 1.3 V 1.6 V 100 uA 24 nC Through Hole
HCO65S06D1 Active Industrial Die Single eSiC D1 650 V 6.0 A 33.8 A 1.3 V 1.6 V 100 uA 24 nC Surface Mount
HCH65S04D1 Active Industrial TO220 2L Single eSiC D1 650 V 4.0 A 23.0 A 1.3 V 1.6 V 100 uA 17 nC Through Hole
HCF65S04D1 Active Industrial TO220F 2L Single eSiC D1 650 V 4.0 A 23.0 A 1.3 V 1.6 V 100 uA 17 nC Through Hole
HCO65S04D1 Active Industrial Die Single eSiC D1 650 V 4.0 A 23.0 A 1.3 V 1.6 V 100 uA 17 nC Surface Mount
HCA65D50D1Q Active Industrial TO247 2L Single eSiC D1Q 650 V 50.0 A 194.0 A 1.4 V 1.7 V 100 uA 148 nC Through Hole
HCW65D40D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 650 V 40.0 A 95.0 A 1.4 V 1.7 V 100 uA 61 nC (Per Leg) Through Hole
HCW65D40D1QA Active Automotive TO247 3L Common Cathode eSiC D1Q 650 V 40.0 A 95.0 A 1.4 V 1.7 V 100 uA 61 nC (Per Leg) Through Hole
HCW65D30D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 650 V 30.0 A 73.0 A 1.4 V 1.7 V 100 uA 48 nC (Per Leg) Through Hole
HCW65D30D1QA Active Automotive TO247 3L Common Cathode eSiC D1Q 650 V 30.0 A 73.0 A 1.4 V 1.7 V 100 uA 48 nC (Per Leg) Through Hole
HCW65D20D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 650 V 20.0 A 50.0 A 1.4 V 1.7 V 100 uA 31 nC (Per Leg) Through Hole
HCW65D20D1QA Active Automotive TO247 3L Common Cathode eSiC D1Q 650 V 20.0 A 50.0 A 1.4 V 1.7 V 100 uA 31 nC (Per Leg) Through Hole
HCA65S20D1Q Active Industrial TO247 2L Single eSiC D1Q 650 V 20.0 A 95.0 A 1.4 V 1.7 V 100 uA 62 nC Through Hole
HCA65S20D1QA Active Automotive TO247 2L Single eSiC D1Q 650 V 20.0 A 95.0 A 1.4 V 1.7 V 100 uA 62 nC Through Hole
HCH65S20D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 20.0 A 95.0 A 1.4 V 1.7 V 100 uA 61 nC Through Hole
HCF65S20D1Q Active Industrial TO220F 2L Single eSiC D1Q 650 V 20.0 A 95.0 A 1.4 V 1.7 V 100 uA 61 nC Through Hole
HCB65S20D1Q Active Industrial D2PAK Single eSiC D1Q 650 V 20.0 A 95.0 A 1.4 V 1.7 V 100 uA 61 nC Surface Mount
HCW65D16D1Q Active Industrial TO247 3L Common Cathode eSiC D1Q 650 V 16.0 A 38.0 A 1.4 V 1.7 V 100 uA 24 nC (Per Leg) Through Hole
HCW65D16D1QA Active Automotive TO247 3L Common Cathode eSiC D1Q 650 V 16.0 A 38.0 A 1.4 V 1.7 V 100 uA 24 nC (Per Leg) Through Hole
HCH65S16D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 16.0 A 73.0 A 1.4 V 1.7 V 100 uA 47 nC Through Hole
HCH65S12D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 12.0 A 62.0 A 1.4 V 1.7 V 100 uA 39 nC Through Hole
HCF65S12D1Q Active Industrial TO220F 2L Single eSiC D1Q 650 V 12.0 A 62.0 A 1.4 V 1.7 V 100 uA 39 nC Through Hole
HCB65S12D1Q Active Industrial D2PAK Single eSiC D1Q 650 V 12.0 A 62.0 A 1.4 V 1.7 V 100 uA 39 nC Surface Mount
HCH65S10D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 10.0 A 50.0 A 1.4 V 1.7 V 100 uA 32 nC Through Hole
HCF65S10D1Q Active Industrial TO220F 2L Single eSiC D1Q 650 V 10.0 A 50.0 A 1.4 V 1.7 V 100 uA 32 nC Through Hole
HCH65S08D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 8.0 A 38.0 A 1.4 V 1.7 V 100 uA 32 nC Through Hole
HCF65S08D1Q Active Industrial TO220F 2L Single eSiC D1Q 650 V 8.0 A 38.0 A 1.4 V 1.7 V 100 uA 32 nC Through Hole
HCH65S06D1Q Active Industrial TO220 2L Single eSiC D1Q 650 V 6.0 A 26.0 A 1.5 V 1.8 V 100 uA 17 nC Through Hole
HCF65S06D1Q Active Industrial TO220F 2L Single eSiC D1Q 650 V 6.0 A 26.0 A 1.5 V 1.8 V 100 uA 17 nC Through Hole
